DRACO
Observatory-class deep-sky imaging in a smart telescope you can actually carry.
A serious astrophotography system, integrated.
Draco combines a 90 mm fast optical system, high-resolution imaging, real-time guiding, physical field-rotation correction, active cooling and automated control into one portable smart observatory.
Large-Aperture Telephoto Optics
More light-gathering power helps reveal faint structures, fine textures and subtler deep-sky detail.
Long Single-Frame Exposures
Built-in guiding and field-rotation correction support exposures up to five minutes per frame.
Physical CMOS Rotation
Frame your target the way you want while the sensor can physically rotate to help counter field rotation.
Aperture where it matters.
Draco uses a 90 mm catadioptric telephoto system with a 340 mm focal length and a fast f/3.8 focal ratio. The large 1/1.3-inch telephoto sensor can operate at high native resolution or use 2×2 binning for stronger low-light signal collection.
Let time bring out the detail.
Draco combines an independent guide-scope sensor, real-time tracking correction and physical CMOS rotation. The result is an integrated system designed to reduce star trailing and field rotation during long exposures.
Cool the sensor. Help keep the optics clear.
Active CMOS cooling reduces thermal noise at the source. Draco also reuses sensor heat to help warm the lens, providing automatic dew prevention during cold or humid imaging sessions.
Its specified operating range extends from -20°C to 45°C, making Draco a genuinely field-oriented imaging system rather than a fair-weather-only gadget.
One telescope. Two views of the night.
Draco can capture through its telephoto and wide-angle cameras in the same session. Use the main telescope for your astronomical target while the ultra-wide camera records the larger sky and landscape around it.
Standard versatility or dedicated SHO nebula imaging.
Both editions share Draco's core telescope, guiding, cooling, sensor rotation, dual-camera system and smart workflow. The key difference is the filter system.
Draco Standard
For general deep-sky, solar, lunar, planetary and wide-field imaging.
- 90 mm f/3.8 telephoto system
- Built-in guiding and CMOS rotation
- Active sensor cooling
- Hα + OIII dual-narrowband filter
- Built-in OD5 solar filter
- EQ Mode and Pro Mode
Draco SHO
For imagers who want automated narrowband capture and Hubble-palette-style SHO compositions.
- Everything in Draco's core imaging system
- Hα + OIII dual-narrowband filter
- SII + OIII dual-narrowband filter
- Dedicated SHO composite workflow
- External magnetic solar filter
- EQ Mode and Pro Mode
Standard vs. SHO
| Feature | Draco Standard | Draco SHO |
|---|---|---|
| 90 mm / 340 mm / f/3.8 optics | Yes | Yes |
| Up to 300-second telephoto exposures | Yes | Yes |
| Built-in guide scope | Yes | Yes |
| Physical CMOS rotation | Yes | Yes |
| Active CMOS cooling | Yes | Yes |
| Hα + OIII dual narrowband | Yes | Yes |
| SII + OIII dual narrowband | — | Yes |
| Solar filter | Built-in OD5 | External magnetic |
| Best fit | General-purpose astrophotography | Narrowband nebula / SHO imaging |
Observatory power without an observatory-sized setup.
A 5.5 kg integrated body, approximately five hours of astronomy-mode battery life, 128 GB of onboard storage and USB-C connectivity make Draco practical for the backyard, a dark-sky site or the road.
Choose it. Frame it. Capture it.
Draco is designed around an automated mobile workflow, from finding targets and previewing composition to guiding, capture, stacking and image processing.
NFC + Auto Connection
Get into the app and connected quickly.
AR Sky Finder
Use the wide-angle sky view to understand what is visible around you.
Composition Preview
Preview framing and orientation before the exposure sequence begins.
Advanced Output
Pro Mode plus FITS/TIFF export supports deeper processing workflows.
The numbers behind Draco.
| Optical System | |
|---|---|
| Aperture | 90 mm |
| Telephoto focal length | 340 mm |
| Telephoto focal ratio | f/3.8 |
| Optical design | Catadioptric |
| Telephoto sensor | OV50Q40, 1/1.3-inch |
| Telephoto resolution | Up to 50.33 MP in astronomical mode |
| Telephoto sampling | 0.73"/pixel native; 1.45"/pixel in 2×2 binning |
| Telephoto exposure range | 1/10000 to 300 seconds |
| Tracking & Imaging | |
| Guide scope | Built-in independent sensor with real-time tracking correction |
| CMOS rotation | ±90° |
| Sensor cooling | Supported |
| Mount movement | 360° rotation; 225° pitch range |
| Body & Connectivity | |
| Storage | 128 GB built in |
| Wireless | Wi-Fi, Bluetooth, NFC |
| USB | USB 3.0 Type-C for charging and data |
| Dimensions | 196 × 133 × 386 mm |
| Weight | 5.5 kg / 12.1 lb |
| Battery | 77 Wh; approximately 5 hours in Astronomy Mode |
| Operating range | -20°C to 45°C |
| Base mount | 3/8-inch threaded hole |
Questions before you choose.
What is Draco?
Draco is an all-in-one smart observatory focused on astrophotography. It combines a 90 mm telescope, telephoto and wide-angle cameras, guiding, physical field-rotation correction, cooling, tracking, capture and app-based processing in an integrated 5.5 kg system.
How is Draco different from DWARF 3 or DWARF mini?
DWARF mini prioritizes compact entry-level use and DWARF 3 emphasizes portable multi-scenario imaging. Draco is the performance-focused step up, with larger aperture, faster optics, longer single-frame exposures, built-in guiding, sensor cooling, physical field-rotation correction and a more observatory-like workflow.
Should I choose Standard or SHO?
Choose Standard if you want the broadest all-around astronomy and solar capability. Choose SHO if nebulae and automated sulfur/hydrogen/oxygen narrowband imaging are a priority. The SHO model adds an SII + OIII narrowband filter and uses an external magnetic solar filter.
Can both cameras capture at the same time?
Yes. Draco can capture telephoto and wide-angle views during the same session, giving you both the detailed target and the wider environment.
Can Draco image from a city?
Yes. The Moon, Sun, brighter clusters and brighter nebulae are suitable urban targets. Fainter galaxies, nebulae and dust structures generally benefit from darker skies and longer total integration time.
Can Draco photograph the Sun?
Yes, only with the approved solar workflow. The Standard Edition uses its built-in OD5 solar filter. The SHO Edition uses the supplied external magnetic solar filter. Always follow the in-app solar safety process.
Does Draco replace a traditional telescope?
Draco can replace many components of a conventional imaging rig, but it does not provide visual eyepiece observing. It is best thought of as an integrated imaging observatory rather than a universal replacement for every telescope.
A new kind of smart observatory.
90 mm aperture. f/3.8 optics. Cooled imaging. Built-in guiding. 300-second exposures. Physical CMOS rotation. Dual-camera capture.
